6 Chadwick-Helmuth Company, Inc.
Chapter 2 - System Overview
2.2 Product Description
This section gives a general description of the Vibrex 2000 and
Vibrex 2000 Plus systems, including the differences between the two
products.
NOTE: See the “Glossary” on page 161 for definitions of specific
Vibrex 2000 and Vibrex 2000 Plus-related terms that may not be
familiar to the user.
Keep in mind that the Vibrex 2000 Plus system has all the capabilities of
the Vibrex 2000. In addition, it has the added features and benefits listed
under Section 2.2.2 “Vibrex 2000 Plus Enhancements” on page 9.
For more details information on both the Vibrex 2000 and
Vibrex 2000 Plus systems, as well as the exact differences between the
two models, see Section 2.3 “System Specifications” on page 10.
2.2.1 Vibrex 2000 System Overview
The Vibrex 2000 unit is a hand-held, battery-powered vibration analyzer.
It is a vibration analysis and balancing tool that rapidly and accurately
acquires and analyzes aircraft vibration data. It uses that data to calculate
balance solutions and to analyze aircraft vibration levels across a broad
frequency range.
The Vibrex 2000 system provides accurate helicopter vibration readings
for chart calculations on main and tail rotors, shafts, and blowers. As a
spectrum analyzer, they provide the operator with an overview of rotor
and drive-train vibration. The Vibrex unit uses the cables and transducers
(for example, the Chadwick-Helmuth Model 7310 Velocimeter, magnetic
pickups, and photocells) from previous generations of our equipment,
further reducing the cost of ownership.
