Printing Data
Vibrex 2000 and Vibrex 2000 Plus User Guide 23
For example, selecting configuration 1A means the Vibrex unit is using
channels No. 1 and A. The channel names shown in the previous table
represent the following values:
• Numbers refer to the Velocimeter (vibration) transducer channel(s)
the Vibrex unit is using and show values in IPS.
• Letters refer to the photocell or magnetic pickup (azimuth) channel(s)
being used and show values in RPM.
Choosing a Channel Entry -
As many times as necessary, press the
context key next to the screen display line that contains the angle
brackets, until the desired channel entry displays.
3.3 Printing Data
The Vibrex 2000 and Vibrex 2000 Plus allow the user to print hard-copy
readouts of collected data or status information. The systems print
through an RS-232 serial port on the connector subpanel. Because of the
large selection of serial printers, it is impossible to address every setup for
every printer. For details, refer to any appropriate PC and/or printer
manual that pertains to the user’s computer system.
3.3.1 Direct Serial Printing
To connect the Vibrex unit to a Seiko Model DPU-414 printer, connect
the nine-pin DBA female cable that terminates against a 9- to 25-pin male
adapter. Use an adapter that has the No. 5 pin of the 9-pin connector
switched to the No. 7 pin of the 25-pin connector.
This switching can occur on the adapter or in the 9- to 9-pin cable or in
the 9- to 25-pin connector. This type of setup works for most other serial
printers as well.
