Routine Servicing
Vibrex 2000 and Vibrex 2000 Plus User Guide 137
6.3.7 Complete Unit Disassembly
This section explains how to completely disassemble and reassemble the
Vibrex 2000 and Vibrex 2000 Plus units, under the following topics:
• Section 6.3.7.1 “Parts List” on page 142
• Section 6.3.7.2 “Disassembly” on page 143
• Section 6.3.7.3 “Assembly” on page 144
Vibrex Unit Diagram - The illustration on page 138 shows an exploded
diagram of the complete unit’s assembly, including all components
referred to in procedures given in this chapter. Required tools are two
screwdrivers, as described in the table on page 127.
NOTE: The numbers in the exploded diagram designate reference
numbers for parts. For the corresponding part names, see the table
under Section 6.3.7.1 “Parts List” on page 142.
