Spectrum Analysis
Vibrex 2000 and Vibrex 2000 Plus User Guide 109
5.6 Spectrum Analysis
After any type of balance operation, if the user feels additional vibrations,
the user can use the Spectrum Analysis feature of the Vibrex 2000 and
Vibrex 2000 Plus to determine the probable source of the vibration. This
feature allows the user to collect extensive, detailed spectral data.
5.6.1 Spectrum Analysis Setup
Access and set up this feature, as follows:
1. From the Main Menu screen, press the
SPECTRUM ANALYSIS
context key.
This action displays the Spectrum Setup screen (see example below).
The example shown above is for the Vibrex 2000, but, with minor
differences, both units display the same screen.
2. Select the appropriate channel by pressing the
CHANNEL
context
key.
<#1> VIB SENSOR
<A> AZIMUTH SENSOR
0-<24,000> RPM
=== SPECTRUM SETUP===
if ok, push START
SELECT TO
ENTER
VELOCIMETER
SETUP
SELECT TO
ENTER SETUP
FOR PHOTOCELL
OR MODEL 3030
MAGNETIC
PICKUP
SELECT TO
ENTER AZIMUTH
RPM RANGE
