Chapter 5 - General Operation
5.6.4.2 Displaying Cursor Data
The Vibrex 2000 Plus also allows the user to display specific data
associated with the current cursor position. Do this action, as follows:
1. In the Spectrum Viewer screen, place the cursor on the desired peak.
2. Press the
?
context key. The Cursor Data screen displays (see below).
This screen gives the user specific vibration data on the current cursor
position.
0- 30,000 RPM
CURRENT CURSOR DATA
0.86 IPS 15300 RPM
1.1 mils Pk-Pk
3.6 Gs 255.0 Hz
" " LIST 1
17JAN00 16:54:46 1A
