24 Chadwick-Helmuth Company, Inc.
Chapter 3 - Getting Started
3.3.1.1 Basic Settings
See the following table for a list of the basic settings to use for
downloading data from the Vibrex 2000 or Vibrex 2000 Plus to any
printer and/or serial interface.
3.3.1.2 Connecting the Printer
Connect a Seiko Model DPU-414 printer to the Vibrex 2000 or
Vibrex 2000 Plus, as follows:
1. Connect the printer cable No. 610-449 to the Vibrex unit and the
printer.
2. Turn the printer ON and press the
ONLINE button if the on-line light-
emitting diode (LED) is not illuminated.
3. Select the desired information to be printed in the Vibrex unit and
press
PRINT.
NOTE: If the batteries are depleted in the DPU-414, connect the ac
wall adapter (No. 610-463 for 110 Vac or No. 610-463A for 220 Vac)
and operate the printer normally.
Setting DIP Switches -
The start-up settings and input method can be
set by the DIP switches (DIP SW). Set the printer’s DIP switches, as
follows:
1. Slide the power switch to OFF.
2. Slide the power switch to ON while pressing the
ONLINE button.
Release the
ONLINE button after a list of the current settings starts
printing out (see page 26).
Parameter Setting
Baud rate 9600
Number of bits 8
Number of stop bits 1
Parity None
Xon/Xoff Supported
