22 Chadwick-Helmuth Company, Inc.
Chapter 3 - Getting Started
REVIEW Reviews data and solutions that were part of a
previous exercise, for example, a propeller balance or
spectrum.
PRINT
Offers selections of data in the memory that the user
can print. For details on the printing feature, see
Section 3.3 “Printing Data” on page 23.
SPACE Acts as a multi-functional key. Use it as a space when
entering information, changing signs for numbers,
and entering slashes. The user may also use it to
return directly to the main menu. This function is
available only on inactive screens, that is, screens
with no active revolutions per minute (RPM) or test.
3.2.2.3 Context Keys
There are four unlabeled keys to the left of the display. These are the
context keys. One or more of these keys may be active when there is a
pointer on the display next to the key on the front panel.
These keys perform operations relevant to the screen currently displayed,
for example, data entry, channel selections, or making other choices.
3.2.3 Channel Configuration
The table below shows the Vibrex 2000 and Vibrex 2000 Plus units’
channel configuration choices.
RPM A RPM B
Velocimeter No. 1
1A 1B
Velocimeter No. 2
2A 2B
