Chen Hsong CDC-2000 - Page 23

CDC-2000
操作手冊
Operational Manual
2.5. Setup for Mold Closing and Opening
2.5.1. Mold closing and mold opening for toggle clamping
Mold close mold open setting ????.?mm
?????p
high speed low speed high pressure
velocity % AA DD GG clamping force
pressure % BB EE HH TTTton
time vvv.v
Location mm CCC.C FFFFFp IIIIIp
Back press % ee ff gg
hhh.h iii.i
reduced speed high speed low speed
PP MM JJ velocity %
QQ NN KK essure %
RRR.R OOO.O LLLLLp location mm
UU TT SS back pressure%
Super high clamping :
ｊ backup function : ｋ
Special mold function :
ｌ
Start location operat distance velocity pressure
Mold close WWWW.W ZZZ.Z XX YY
Mold open aaaa.a ddd.d bb cc
High pre. eject. Core. Unscrew air. Modul. Labr.
S
p
l.nuts mold
Chart 03
F1 F2 F3
F4 F5
F6
F7
F8
F9 F10
pr
2.5.1.1. Mold-closing Setting
Move cursor to the desired parameter for mold closing. Key in desired digits through digit
keys and press
to complete a correction.
The setting description of the “Mould opening & closing“ Menu (03) are shown below:
A) AA : Booster cylinder fast mold-closing speed setup.
B) BB : Booster cylinder fast mold-closing pressure setup.
C) ee : Booster cylinder fast mold-closing counter-balance pressure setup.
D) CCC.C : Booster cylinder fast mold-closing end-position setup.
E) DD : Booster cylinder low-pressure mold-closing speed setup.
F) EE : Booster cylinder low-pressure mold-closing pressure setup.
G) ff : Booster cylinder low-pressure mold-closing counter-balance setup.
H) FFFFF : Booster cylinder low-pressure mold-closing end-position setup.
I) vvv.v : Booster cylinder low-pressure mold-closing time setup.
J) GG : Booster cylinder mold-closing pressure confirmed setup.
K) HH : Booster cylinder fast mold-closing pressure confirmed setup.
L) gg : Booster cylinder fast mold-closing counter-balance pressure confirmed
04/08/13
19
