C.h) cc :Mold-opening pressure setup for booster cylinder special mold.
2.5.2. High-Pressure Cylinder Mold-Closing and Mold-Opening Setup
Mold-closing mold-opening setup ????.?mm
?????p
fast speed low-pressure high-pressure
velocity % AA DD GG clamping force
pressure % BB EE HH TTT Ton
time (sec) vvv.v
docation mm CCC.C FFFFFp IIIIIp
back pressure% ee ff gg
hhh.h iii.i
reduced speed fast speed low speed
PP MM JJ velocity %
QQ NN KK pressure %
RRR.R OOO.O LLLLLp docation mm
UU TT SS back pressure%
Super high clanying :
ｊ backup function : ｋ
Special mold function :
ｌ
Start cocation operat.distance velocity pressure
Mold-closing WWWW.W ZZZ.Z XX YY
Mold-opening aaaa.a ddd.d bb cc
Hi pre. Eject. Co pull unscr. Air.bl modul. Lubri.
S
l.unts
Chart 03
F1 F2 F3
F4 F5
F6
F7
F8
F9 F10
2.5.2.1. Mold-Closing Setup
Move the cursor to the desired parameter for high-pressure cylinder. Key in your desired
digits and press
to complete the correction.
Code description for Menu (03) are as follows:
A) AA : speed setup for high-pressure cylinder high-speed mold-closing.
B) BB : pressure setup for high-pressure cylinder high-speed mold-closing.
C) ee : back pressure setup for high-pressure cylinder high-speed mold-closing.
D) CCC.C : end-position setup for high-pressure cylinder high-speed mold-closing.
E) DD : speed setup for high-pressure cylinder low-pressure mold-closing.
F) EE : pressure setup for high-pressure cylinder low-pressure mold-closing.
G) ff : back pressure setup for high-pressure cylinder low-pressure mold-closing.
H) FFFFF: end-position setup for high-pressure cylinder low-pressure mold-closing.
I) vvv.v : time setup for high-pressure cylinder low-pressure mold-closing.
J) GG : speed setup for high-pressure cylinder high-pressure mold-closing.
K) HH : pressure setup for high-pressure cylinder high-pressure mold-closing.
04/08/13
22
To Next Page
