Video Pattern Generator 2238 User’s Manual
B-20
72
CHARAC/H-5R
It is the reverse pattern of pattern # 71.
73
CHARAC/CX-5
The pattern is all composed of “CX”. The
font type is 5  7.
74
CHARAC/CX-5R
It is the reverse pattern of pattern # 73.
75
CHARAC/ME
The pattern is all composed of “E” in
up/down/left/right direction. The font type is
11 x 11.
76
CHARAC/ME-R
It is the reverse pattern of pattern # 75.
77
ROOT WEAVE
The pattern is all composed of “root”. It is
used to check moire.
78
CHARAC/16X15
The pattern is all composed of “ ” (Hui).
The font type is 16 x 15.
79
CHARAC/24X24
The pattern is all composed of “ ” (Ying).
The font type is 24 x 24.
80
CHARAC/@
The pattern is all composed of “@”. The font
type is 5 x 7.
81
CHARAC/H-7
The pattern is all composed of “H”. The
font type is 7 x 9.
82
CHARAC/H-7R
It is the reverse pattern of pattern # 81.
