ChroMate™ ChroMate™ Operator’s Manual Doc. 4300 Rev. E 63
Calibration Tab (Continued)
Feature: Description: Item No.:
Choose
Assay
Use the drop-down menu to choose one of the
assays from the list.
1
Add
Calibration
Test
Information
Lists the calibrators and controls by name, copies
required, and whether or not they are valid.
Selections –
• Select the Curve option to insert a blank and a
calibrator for the assay into the work list. Select
multiple times to add more copies of each. This
button is not active if the user is running an
assay that does not require calibrators.
• Select the Control option to add all of the
Controls specified in the assay. Press the
button multiple times to add multiple copies of
the controls.
• NOTE: The user may also select calibrators,
controls, and blanks individually.
2
View
Results
View the calibration and control results in this
area.
3
Accept
Selected
Button
To edit the curve, check the curve records
(choose part of curve records which look good to
user), then click the Accept Selected button.
This button will be enabled once the software
calculates (based on time, logic, math, etc.) a
valid curve.
After activating new curve records, the stored
curve is changed. The software will look at the test
list to recalculate all finished tests of this assay.
4
Discard
New
The Discard New button allows the user to discard
the newly created curve and return to the previous
curve.
5
Print
Preview
Preview calibration and control results before
printing statistics such as %CV, %Dif, and mean
values are also shown.
6
Print Report Allows the user to print the selected assay.
7
