ChroMate™ ChroMate™ Operator’s Manual Doc. 4300 Rev. E 81
Steps Prompts/Screen Display
ChroMate Communication (COM) Port Setting (Continued):
and then the Plate Layout screen will display:
Plate Layout Display
Click on the
Settings tab on the
ChroMate Manager
Menu Bar to access
the Comm Port
setting:
Click on the “Comm
Port, Database,
Report…” option on
the Settings drop
down menu:
