The icon flashes during the delay time in the alarm connection (ON) and
disconnection (OFF).
5�1�3�1�1�1�- Instantaneous parameters display menu�
Figure 124 shows the instantaneous parameters display menu.
Figure 124: Instantaneous parameters, display menu (display 4 parameters)�
>
>
>
<
<
<
varh
THD
A
VPh-n
...
Graphic
view
Back
Main
menu
Figure 125: Instantaneous parameters menu�
The menu in the lower area disappears after 3 seconds. Press the key to display the lower
area again.
108
CVM-A1000 - CVM-A1500
Instruction Manual
