Circutor CVM-A1500 User Manual

5�6�3�3�- Analogue Inputs/Outputs expansion modules
The screen in Figure 230, is one of the information display screens for the expansion module.
Figure 230: Analogue outputs information screen (Analogue Inputs/Outputs Module)�
This screen displays the conguration of the analogue inputs of the module.
The following options appear in the lower area:
>
>
<
<
>
<
>
<
x
Main
menu
Back
Analog
Inputs
Analog
Outputs
Figure 231: Analogue Inputs/Outputs Module menu�
Use the keys and to select the different options.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
166
CVM-A1000 - CVM-A1500
Instruction Manual
