Use the keys and to select the different options.
To conrm the selection, press the key .
After selecting the output to congure, Figure 293, the following parameters can be congured:
 The variable code that controls the relay.
 The Pre-alarm value.
 The minimum value below which the relay is activated.
 The maximum value above which the relay is activated.
 The delay in connecting and disconnecting the relay.
 The status of the outputs.
 The latch.
Figure 293: Conguration screen of relay digital outputs.
The parameter selected is indicated in white.
>
<
>
>
>
>
>
<
<
<
<
<
1
>
<
>
<
Conguration
values
Previous
Next
Conrm
and save
Delete
parameter
Back
Main
menu
Delete
character
Figure 294: Setup menu:Relay digital outputs�
200
CVM-A1000 - CVM-A1500
Instruction Manual
