Use the keys and to select the different options.
To conrm the selection, press the key .
● For programming the variable code which controls the relay digital output, you need the
Table 32 and Table 33:
Note: To cancel the operation of a digital output, the 0 code must be programmed.
Table 32: Code of variables for programming the digital outputs and transistor�
Variable Phase Code Phase Code Phase Code Phase Code
Phase-Neutral Voltage L1 1 L2 9 L3 17 III 31
Current L1 2 L2 10 L3 18 III 33
Active power L1 3 L2 11 L3 19 III 34
Inductive Reactive Power L1 4 L2 12 L3 20 III 35
Capacitive Reactive Power L1 5 L2 13 L3 21 III 36
Total Reactive Power L1 69 L2 70 L2 71 III 72
Apparent Power L1 6 L2 14 L3 22 III 37
Power factor L1 7 L2 15 L3 23 III 38
Cosine φ L1 8 L2 16 L3 24 III 39
% THD V L1 40 L2 41 L3 42 LN 43
% THD A L1 44 L2 45 L3 46 LN 47
Phase-Phase Voltage L1/2 28 L2/3 29 L3/1 30 III 32
Neutral voltage - 25 - - -
Neutral current
(21)
- 26 - - -
Frequency - 27 - - -
Variable
L1 L2 L3 III
Active Energy Generated
(25)
T1 149 T1 154 T1 159 T1 164
T2 189 T2 194 T2 199 T2 204
T3 229 T3 234 T3 239 T3 244
Total 509 Total 514 Total 519 Total 524
Active Energy Consumed
(25)
T1 129 T1 134 T1 139 T1 14
T2 169 T2 174 T2 179 T2 184
T3 209 T3 214 T3 219 T3 224
Total 489 Total 494 Total 499 Total 504
Inductive Reactive Energy
Generated
(25)
T1 150 T1 155 T1 160 T1 165
T2 190 T2 195 T2 200 T2 205
T3 230 T3 235 T3 240 T3 245
Total 510 Total 515 Total 520 Total 525
Inductive Reactive Energy
Consumed
(25)
T1 130 T1 135 T1 140 T1 145
T2 170 T2 175 T2 180 T2 185
T3 210 T3 215 T3 220 T3 225
Total 490 Total 495 Total 500 Total 505
Capacitive Reactive Ener-
gy Generated
(25)
T1 151 T1 156 T1 161 T1 166
T2 191 T2 196 T2 201 T2 206
T3 231 T3 236 T3 241 T3 246
Total 511 Total 516 Total 521 Total 526
201
Instruction Manual
CVM-A1000 - CVM-A1500
