Table 32 (Continuation): Code of variables for programming the digital outputs and transistor�
Variable
L1 L2 L3 III
Capacitive Reactive
Energy Consumed
(25)
T1 131 T1 136 T1 141 T1 146
T2 171 T2 176 T2 181 T2 186
T3 211 T3 216 T3 221 T3 226
Total 491 Total 496 Total 501 Total 506
Total Reactive Energy
Generated
(25)
T1 152 T1 157 T1 162 T1 167
T2 192 T2 197 T2 202 T2 207
T3 232 T3 237 T3 242 T3 247
Total 512 Total 517 Total 522 Total 527
Total Reactive Energy
Consumed
(25)
T1 132 T1 137 T1 142 T1 147
T2 172 T2 177 T2 182 T2 187
T3 212 T3 217 T3 222 T3 227
Total 492 Total 497 Total 502 Total 507
Apparent Energy
Generated
(25)
T1 153 T1 158 T1 163 T1 168
T2 193 T2 198 T2 203 T2 208
T3 233 T3 238 T3 243 T3 248
Total 513 Total 518 Total 523 Total 528
Apparent Energy
Consumed
(25)
T1 133 T1 138 T1 143 T1 148
T2 173 T2 178 T2 183 T2 188
T3 213 T3 218 T3 223 T3 228
Total 493 Total 498 Total 503 Total 508
Maximum current demand
T1 600 T1 601 T1 602 T1 603
T2 612 T2 613 T2 614 T2 615
T3 624 T3 625 T3 626 T3 627
Total 828 Total 829 Total 830 Total 831
Active Power Maximum
Demand
T1 604 T1 605 T1 606 T1 607
T2 616 T2 617 T2 618 T2 619
T3 628 T3 629 T3 630 T3 631
Total 832 Total 833 Total 834 Total 835
Apparent Power Maximum
Demand
T1 608 T1 609 T1 610 T1 611
T2 620 T2 621 T2 622 T2 623
T3 632 T3 633 T3 634 T3 635
Total 836 Total 837 Total 838 Total 839
Variable Integrated
(22)
Digital input I1
(24) (26)
900 - - -
Digital input I2
(24) (26)
901 - - -
Variable Module 1
(23)
Module 2
(23)
Module 3
(23)
Module 4
(23)
Digital input I1
(24) (26)
902 910 918 926
Digital input I2
(24) (26)
903 911 919 927
Digital input I3
(24) (26)
904 912 920 928
Digital input I4
(24) (26)
905 913 921 929
Digital input I5
(24) (26)
906 914 922 930
Digital input I6
(24) (26)
907 915 923 931
Digital input I7
(24) (26)
908 916 924 932
Digital input I8
(24) (26)
909 917 925 933
202
CVM-A1000 - CVM-A1500
Instruction Manual
