Table 58 (Continuation): Modbus memory map: Conguration variables (Energy cost)
Energy cost
Configuration variable Address Valid data window Default value
Cost per kWh of tariff 3 generation 27E2-27E3 0 to 100
(47)
0
Currency 27E4-27E7 7 ascii characters EURO
(47)
The number of decimals are indicated at address 0x1586. Format of the units: Power of 10 (with sign).
Note: The 16 registers must be written and read at once (as a group), otherwise it will respond
with an error.
6�3�10�12�- CO
2
consumption and generation emissions
These parameters occupy 2 registers each.
Table 59:Modbus memory map: Conguration variables (CO
2
emissions)
C0
2
emissions
Configuration variable Address Valid data window Default value
Tariff 1 consumption emissions ratio 2774-2775 0 to 100
(48)
0
Tariff 2 consumption emissions ratio 2776-2777 0 to 100
(48)
0
Tariff 3 consumption emissions ratio 2778-2779 0 to 100
(48)
0
Tariff 1 generation emissions ratio 277A-277B 0 to 100
(48)
0
Tariff 2 generation emissions ratio 277C-277D 0 to 100
(48)
0
Tariff 3 generation emissions ratio 277E-277F 0 to 100
(48)
0
(48)
The number of decimals are indicated at address 0x1585. Format of the units: Power of 10 (with sign).
Note: The 12 registers must be written at once (as a group), otherwise it will respond with an
error.
6�3�10�13�- Relay digital outputs
The Maximum Value and Minimum Value conguration variables occupy 2 registers each.
All other variables occupy 1 register each.
Table 60:Modbus memory map: Relay digital outputs�
Conguration of the digital outputs of the relay
Configuration variable
Address
Valid data margin Default value
Output 1 Output 2
Maximum value
(49)
4E48-4E49 4E5C-4E5D Table 61 0
Minimum value
(49)
4E4A-4E4B 4E5E-4E5F Table 61 0
Connection delay (ON) 4E4C 4E60 0 to 999 seconds 0
Disconnection delay (OFF) 4E4D 4E61 0 to 999 seconds 0
Pre-alarm value 4E4E 4E62 0 to 100 % 0
Output status 4E4F 4E63
0 : Normally open
1: Normally closed
0
Interlocking (latch) 4E50 4E64
0 : Unlocked
1: Locked
0
Not used 4E51 4E65 0 0
Variable code 4E52 4E66 Table 32 0
Module no. 4E53 4E67 0 0
(49)
The decimal for the selected variable must be included when programming the maximum and minimum values.
246
CVM-A1000 - CVM-A1500
Instruction Manual
