for this mode simultaneously.
(59)
the characters must be sent in hexadecimal.
Note: The 11 registers must be written and read at once (as a group), otherwise it will respond
with an error.
6�3�10�16�- Integrated communications
These parameters occupy 1 register each.
Table 64:Modbus memory map: Conguration variables (Communications)
Communications
Configuration variable Address Valid data window Default value
Protocol 2738 0 : Modbus , 1: BACnet 0
Peripheral number 2739 0 to 255 1
Speed 273A
0: 1200 - 1: 2400 - 2: 4800
3: 9600 - 4: 19200 - 5: 38400 -
6: 57600 - 7: 76800 - 8: 115200
4
Parity 273B
0 : No parity
1: Odd parity
2: Even parity
0
Length 273C
1: 8 bits
1
Stop bits 273D
0: 1 stop bit
1: 2 stop bits
0
Note: The 6 registers must be written at once (as a group), otherwise it will respond with an
error.
6�3�10�17�- Módulo Datalogger
Table 65: Modbus memory map: : Datalogger module (Table 1)
TCP parameters
Configuration variable Address Valid data margin Example
DHCP Flag E2AE
0 : Deactivation
1: Activation
-
IP Address E290 - E291 1 long : 4 characters AC109C4B (172.16.156.75)
Subnet Mask E292 - E293 1 long : 4 characters FFFFF000 (255.255.240.0)
Gateway E294 - E295 1 long : 4 characters AC109601(172.16.150.1)
MAC E2A0 - E2A2 3 integers : 6 characters 14A62C001D54 (14.A6.2C.00.1D.54)
Table 66:Modbus memory map: : Datalogger module (Table 2)
Port address and versions
Configuration variable Address Valid data margin
Port E296 - E297 1 long
Embedded version E298 - E29B 4 integers : 8 characters
PowerStudio version E29C - E29F
4 integers : 8 characters
249
Instruction Manual
CVM-A1000 - CVM-A1500
