Table 91:Modbus memory map: Relay digital outputs, expansion modules (Table 4)�
Conguration of the relay digital outputs: Slot 3
Configuration variable
Address
Output
1
Output
2
Output
3
Output
4
Output
5
Output
6
Output
7
Output
8
Maximum value
CB20 CB34 CB48 CB5C CB70 CB84 CB98 CBAC
Minimum value
CB22 CB36 CB4A CB5E CB72 CB86 CB9A CBAE
Delay connection (ON)
CB24 CB38 CB4C CB60 CB74 CB88 CB9C CBB0
Disconnection delay (OFF)
CB25 CB39 CB4D CB61 CB75 CB89 CB9D CBB1
Pre-alarm value CB26 CB3A CB4E CB62 CB76 CB8A CB9E CBB2
Output status CB27 CB3B CB4F CB63 CB77 CB8B CB9F CBB3
Latch CB28 CB3C CB50 CB64 CB78 CB8C CBA0 CBB4
Not used CB29 CB3D CB51 CB65 CB79 CB8D CBA1 CBB5
Variable code
CB2A CB3E CB52 CB66 CB7A CB8E CBA2 CBB6
Module no. CB2B CB3F CB53 CB67 CB7B CB8F CBA3 CBB7
Note: The 12 registers must be written and read at once (as a group), otherwise it will respond
with an error.
Table 92:Modbus memory map: Relay digital outputs, expansion modules (Table 5)�
Conguration of relay digital outputs: Slot 4
Configuration variable
Address
Output
1
Output
2
Output
3
Output
4
Output
5
Output
6
Output
7
Output
8
Maximum value
CF08 CF1C CF30 CF44 CF58 CF6C CF80 CF94
Minimum value
CF0A CF1E CF32 CF46 CF5A CF6E CF82 CF96
Delay connection (ON)
CF0C CF20 CF34 CF48 CF5C CF70 CF84 CF98
Disconnection delay (OFF)
CF0D CF21 CF35 CF49 CF5D CF71 CF85 CF99
Pre-alarm value CF0E CF22 CF36 CF4A CF5E CF72 CF86 CF9A
Output status CF0F CF23 CF37 CF4B CF5F CF73 CF87 CF9B
Latch CF10 CF24 CF38 CF4C CF60 CF74 CF88 CF9C
Not used CF11 CF25 CF39 CF4D CF61 CF75 CF89 CF9D
Variable code
CF12 CF26 CF3A CF4E CF62 CF76 CF8A CF9E
Module no. CF13 CF27 CF3B CF4F CF63 CF77 CF8B CF9F
Note: The 12 registers must be written and read at once (as a group), otherwise it will respond
with an error.
7�2�4�2�- Manual programming of relay digital outputs
The following functions are implemented for these variables:
Function 0x04: reading registers.
Function 0x10: Writing multiple registers.
Table 93: Modbus memory map: Manual programming of outputs, expansion modules (Table 1)�
Manual programming of relay digital outputs
Configuration variable Valid data window Default value
Programming status
(77)
0: Automatic
1:Manual
0
Value
0: Open
1:Closed
0
273
