Table 109: Modbus memory map: Transistor digital outputs, expansion modules (Table 5)�
Transistor Digital Outputs conguration: Slot 4
Configuration variable Address
Alarm
Impulse
output
Output
1
Output
2
Output
3
Output
4
Output
5
Output
6
Output
7
Output
8
Maximum value
Energy
meter factor
CF08 CF1C CF30 CF44 CF58 CF6C CF80 CF94
Minimum value -
CF0A CF1E CF32 CF46 CF5A CF6E CF82 CF96
Delay in the
Connection (ON)
High period CF0C CF20 CF34 CF48 CF5C CF70 CF84 CF98
Delay in the
Disconnection
(OFF)
Low period CF0D CF21 CF35 CF49 CF5D CF71 CF85 CF99
Value of
Pre-alarm
- CF0E CF22 CF36 CF4A CF5E CF72 CF86 CF9A
Status of
The output
- CF0F CF23 CF37 CF4B CF5F CF73 CF87 CF9B
Latch - CF10 CF24 CF38 CF4C CF60 CF74 CF88 CF9C
Not used CF11 CF25 CF39 CF4D CF61 CF75 CF89 CF9D
Variable code
CF12 CF26 CF3A CF4E CF62 CF76 CF8A CF9E
Module no.
CF13 CF27 CF3B CF4F CF63 CF77 CF8B CF9F
Note: The 12 registers must be written and read at once (as a group), otherwise it will respond
with an error.
7�3�4�2�- Manual programming of transistor digital outputs
The following functions are implemented for these variables:
Function 0x04:reading registers.
Function 0x10: Writing multiple registers.
Table 110: Modbus memory map: Manual programming of outputs, expansion modules (Table 1)�
Manual programming of transistor digital outputs
Configuration variable Valid data window Default value
Programming status
(82)
0: Automatic
1:Manual
0
Value
0: Open
1:Closed
0
(82)
When programming the Programming status manually set the output for the transistors manually, using the
Value parameter. The conguration of the transistor digital outputs programmed in the device no longer works.
The transistors work in automatic mode according to the conguration programmed in the device.
Table 111: Modbus memory map: Manual programming of outputs, expansion modules (Table 2)�
Manual programming of transistor digital outputs: Slot 1
Configuration variable
Address
Output
1
Output
2
Output
3
Output
4
Output
5
Output
6
Output
7
Output
8
Programming status C428
C43C C450 C464 C478 C48C C4A0 C4B4
Value
C429
C43D C451 C465 C479 C48D C4A1 C4B5
Note: The 2 registers must be written at once (as a group), otherwise it will respond with an
error.
285
Instruction Manual
CVM-A1000 - CVM-A1500
