Table 116: Modbus memory map: Digital inputs, expansion modules (Table 2)�

Conguration of digital inputs: Slot 1

Configuration variable

Address

Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8

Mode

C4E0

C4EC C4F8 C504 C510 C51C C528 C534

Logic (Logic state)

C4E1

C4ED C4F9 C505 C511 C51D C529 C535

No. of decimals (Impulses) C4E2

C4EE C4FA C506 C512 C51E C52A C536

Not used

C4E3

C4EF C4FB C507 C513 C51F C52B C537

Input name (impulses)

C4E4 -

C4E7

C4F0-

C4F3

C4FC-

C4FF

C508-

C50B

C514-

C517

C520-

C523

C52C-

C52F

C538-

C53B

Units (Impulses)

C4E8 -

C4EA

C4F4-

C4F6

C500-

C502

C50C-

C50E

C518-

C51A

C524-

C526

C530

C532

C53C

C53E

Note: The 11 registers must be written and read at once (as a group), otherwise it will respond

with an error.

Table 117:Modbus memory map: Digital inputs, expansion modules (Table 3)�

Conguration of digital inputs: Slot 2

Configuration variable

Address

Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8

Mode

C8C8

C8D4 C8E0 C8EC C8F8 C904 C910 C91C

Logic (Logic state)

C8C9

C8D5 C8E1 C8ED C8F9 C905 C911 C91D

No. of decimals (Impulses) C8CA

C8D6 C8E2 C8EE C8FA C906 C912 C91E

Not used

C8CB

C8D7 C8E3 C8EF C8FB C907 C913 C91F

Input name (impulses)

C8CC-

C8CF

C8D8-

C8DB

C8E4-

C8E7

C8F0-

C8F3

C8FC-

C8FF

C908-

C90B

C914-

C917

C920-

C923

Units (Impulses)

C8D0-

C8D2

C8DC-

C8DE

C8E8-

C8EA

C8F4-

C8F6

C900-

C902

C90C-

C90E

C918-

C91A

C924-

C926

Note: The 11 registers must be written and read at once (as a group), otherwise it will respond

with an error.

Table 118:Modbus memory map: Digital inputs, expansion modules (Table 4)�

Conguration of digital inputs: Slot 3

Configuration variable

Address

Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8

Mode

CCB0

CCBC CCC8 CCD4 CCE0 CCEC CCF8 CD04

Logic (Logic state)

CCB1

CCBD CCC9 CCD5 CCE1 CCED CCF9 CD05

No. of decimals (Impulses) CCB2

CCBE CCCA CCD6 CCE2 CCEE CCFA CD06

Not used

CCB3

CCBF CCCB CCD7 CCE3 CCEF CCFB CD07

Input name (impulses)

CCB4 -

CCB7

CCC0 -

CCC3

CCCC -

CCCF

CCD8-

CCDB

CCE4-

CCE7

CCF0-

CCF3

CCFC-

CCFF

CD08-

CD0B

Units (Impulses)

CCB8 -

CCBA

CCC4 -

CCC6

CCD0 -

CCD2

CCDC-

CCDE

CCE8-

CCEA

CCF4-

CCF6

CD00-

CD02

CD0C-

CD0E

Note: The 11 registers must be written and read at once (as a group), otherwise it will respond

with an error.

287

Instruction Manual

CVM-A1000 - CVM-A1500
