Table 119:Modbus memory map: Digital inputs, expansion modules (Table 5)�
Conguration of digital inputs: Slot 4
Configuration variable
Address
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8
Mode
D098
D0A4 D0B0 D0BC D0C8 D0D4 D0E0 D0EC
Logic (Logic state)
D099
D0A5 D0B1 D0BD D0C9 D0D5 D0E1 D0ED
No. of decimals (Impulses) D09A
D0A6 D0B2 D0BE D0CA D0D6 D0E2 D0EE
Not used
D09B
D0A7 D0B3 D0BF D0CB D0D7 D0E3 D0EF
Input name (impulses)
D09C-
D09F
D0A8-
D0AB
D0B4-
D0B7
D0C0-
D0C3
D0CC-
D0CF
D0D8-
D0DB
D0E4-
D0E7
D0F0-
D0F3
Units (Impulses)
D0A0-
D0A2
D0AC-
D0AD
D0B8-
D0BA
D0C4-
D0C6
D0D0-
D0D2
D0DC-
D0DE
D0E8-
D0EA
D0F4-
D0F6
Note: The 11 registers must be written and read at once (as a group), otherwise it will respond
with an error.
7�3�4�4�- Status of digital inputs
The following functions are implemented for these variables:
Function 0x04: reading registers.
Table 120: Modbus memory map: Status of digital inputs (Table 1)�
Status of digital inputs: Slot 1
Configuration variable Address Valid data window
Input Status 1 C5A8 – C5A9 0 to 1
Input Status 2 C5AA – C5AB 0 to 1
Input Status 3 C5AC – C5AD 0 to 1
Input Status 4 C5AE – C5AF 0 to 1
Input Status 5 C5B0 – C5B1 0 to 1
Input Status 6 C5B2 – C5B3 0 to 1
Input Status 7 C5B4 – C5B5 0 to 1
Input Status 8 C5B6 – C5B7 0 to 1
Table 121: Modbus memory map: Status of digital inputs (Table 2)�
Status of digital inputs: Slot 2
Configuration variable Address Valid data window
Input Status 1 C990 – C991 0 to 1
Input Status 2 C992 – C993 0 to 1
Input Status 3 C994 – C995 0 to 1
Input Status 4 C996 – C997 0 to 1
Input Status 5 C998 – C999 0 to 1
Input Status 6 C99A – C99B 0 to 1
Input Status 7 C99C – C99D 0 to 1
Input Status 8 C99E – C99F 0 to 1
288
CVM-A1000 - CVM-A1500
Instruction Manual
