7�5�4�3�- Conguration of the RS-485 gateway parameters
The conguration parameters of the RS-485 gateway are, Figure 375:
 The transmission speed, Baud rate.
 The parity.
 The number of stop bits.
Figure 375: Conguration screen of the Modbus TCP (Bridge) module (RS-485 Gateway)
The parameter selected is indicated in white.
>
>
>
>
>
<
<
< <
<
>
<
1
Main menu
Back
Conguration
values
Previous
Next
Conrm
and save
Figure 376: Setup menu : RS-485�
Use the and buttons to select the different options.
To conrm the selection, press the button.
312
CVM-A1000 - CVM-A1500
Instruction Manual
