10�- TECHNICAL FEATURES OF EXPANSION MODULES
10.1.- TRANSISTOR DIGITAL INPUTS/OUTPUTS
General features
Maximum power of the module 3 W
Refresh time 1 s
Response time (outputs) / Detection time (inputs) < 150 ms
Transistor digital outputs
(93)
Quantity 8
Type NPN
Maximum voltage
48 V
Maximum current 120 mA
Maximum frequency 500 Hz
Pulse width 1 ms
Digital inputs
(93)
Quantity 8
Type Potential-free contact
Insulation 4 kV
Input impedance 3 kΩ
Environmental features
Operating temperature -10ºC ... +50ºC
Storage temperature -20ºC ... +80ºC
Relative humidity (without condensation) 5 ... 95%
Maximum altitude 2000 m
Protection degree
(94)
IP30
Mechanical features
Dimensions (mm) Figure 410
Weight 80 g
Enclosure V0 self-extinguishing plastic
Assembly Panel
(93)
Must be connected to SELV circuit.
(94)
This pollution degree hasn’t been tested by UL.
Standards
Safety requirements for electrical equipment for measurement, control
and laboratory use -- Part 1: General requirements
IEC/EN 61010-1:2010
(Third Edition)
Electromagnetic compatibility (EMC) -- Part 6-2: Generic standards - Im-
munity for industrial environments
UNE-EN 61000-6-2:2006
Electromagnetic compatibility (EMC) -- Part 6-4: Generic standards -
Emission standard for industrial environments
UNE-EN 61000-6-4:2007
Insulation coordination for equipment within low-voltage systems -- Part
1: Principles, requirements and tests�
IEC 60664-1:2007
Safety requirements for electrical equipment for measurement, control
and laboratory use -- Part 2-030: Particular requirements for testing and
measuring circuits
IEC 61010-2-030:2010
(First Edition)
Safety requirements for electrical equipment for measurement, control,
and laboratory use - Part 1: General requirements
UL 61010-1 3rd edition, 2012-
05
Safety Requirements for Electrical Equipment for Measurement, Control
and Laboratory Use - Part 1: General Requirements (Adopted IEC 1010-
1:1990 with modications)
CAN/CSA-C22.2 No. 61010-
1, 3rd edition, 2012-05
355
Instruction Manual
CVM-A1000 - CVM-A1500
