Circutor CVM-A1500 User Manual

4.2.2.3. .STD le
The standard (�STD) le is used to store all the parameters that have to be recorded periodical-
ly, within a programmed period of time.
The recording period can be congured with Modbus, see “6.3.9.7.- Quality”
Table 13 shows the variables that can be included in an �STD le.
Table 13: Variables that can be included in the .STD le.
Variables Units
Phases
L1-L2-L3
N
Total
III
Phase-neutral voltage (RMS, maximum, minimum)
Vph-N
  
Phase-phase voltage (RMS, maximum, minimum)
Vph-ph
 
Current (average, maximum, minimum)
A
  
Frequency (average, maximum, minimum)
Hz
(L1)
Active power (average, maximum, minimum)
kW
 
Apparent power (average, maximum, minimum)
kVA
 
Inductive Reactive Power (average, maximum, minimum)
kvarL
 
Capacitive Reactive Power (average, maximum, minimum)
kvarC
 
Power factor (average, maximum, minimum)
PF
 
Cos φ φ
 
Peak factor (voltage and current)
CF

K-factor
-

THD % Voltage (average, maximum, minimum)
% THD V
 
THD % Current (average, maximum, minimum)
% THD A
 
Harmonic Breakdown - Voltage (up to the 63rd harmonic)
harm V
 
Harmonic Breakdown - Current (up to the 63rd harmonic)
harm A
 
PST Flicker
Pst
 
Active energy
kWh
 
Inductive Reactive Energy
kvarLh
 
Capacitive Reactive Energy
kvarCh
 
Apparent energy
kVAh
 
Voltage unbalance
-

Voltage asymmetry
-

Homopolar voltage
-

Forward voltage
-

Reverse voltage
-

Current unbalance
-

Current asymmetry
-

Homopolar current
-

Direct current
-

Reverse current
-

Maximum Current Demand
A
 
Maximum Active Power Demand
kW

Maximum Apparent Power Demand
kVA

45
Instruction Manual
CVM-A1000 - CVM-A1500
