Appendix A Technical Specifications
Network and Access Port Pinouts
Access Port Connector
Table A-3 describes the access port connector pinouts.
Table A-2 Network Port Connector Pinouts
Pin Number Function
1TD+
2TD-
3RD+
4 +48 Volts return
1
1. When used to receive power from an inline
power card in the Cisco Catalyst switch.
5 +48 Volts return
1
6RD-
7 +48 Volts source
1
8 +48 Volts source
1
Table A-3 Access Port Connector Pinouts
Pin Number Function
1RD+
2RD-
3TD+
4Not Used
5Not Used
6TD-
7Not Used
8Not Used

Cisco 7960 Specifications

General

Codecs	G.711, G.729a
Protocol Support	SCCP, SIP
Ethernet Ports	2 x 10/100 Ethernet ports
Power Options	Power over Ethernet (PoE), AC adapter
Audio	Full-duplex speakerphone
Buttons	6 line buttons
Weight	3.5 pounds
