Cisco 7960 Administration Guide

CHAPTER
4-1
Cisco IP Phone Administration Guide for Cisco CallManager 3.2, Cisco IP Phones 7960/7940/7910
78-10453-04
4
Adding the Cisco IP Phone 7914
Expansion Module
The Cisco IP Phone 7914 Expansion Module attaches to the
Cisco IP Phone 7960 and extends its functionality by adding 14 line appearances
and/or speed dial numbers per module. One or two Expansion Modules can be
attached to your IP Phone. One Expansion Module provides a total of 20 line
and/or speed dial numbers. Two Expansion Modules provide a total of 34 line
and/or speed dial buttons, as shown in Figure 4-1.
Figure 4-1 Cisco IP Phone 7960 with Two Expansion Modules

Cisco 7960 Specifications

General

Codecs	G.711, G.729a
Protocol Support	SCCP, SIP
Ethernet Ports	2 x 10/100 Ethernet ports
Power Options	Power over Ethernet (PoE), AC adapter
Audio	Full-duplex speakerphone
Buttons	6 line buttons
Weight	3.5 pounds
