Chapter 11 Cisco ASR 1013 Router Overview and Installation
Cisco ASR 1013 Router Description
Figure 11-2 Cisco ASR 1013 Router—Rear View
1 Cable-management brackets 6 AC power supply in slot 2 (power supply zone
1)
2 Forward rack-mount ears are shipped
installed
7 AC power supply in slot 1 (power supply zone
0)
3 Chassis handle 8 AC power supply in slot 0 (power supply zone
0)
4 Rear rack-mount brackets 9 Chassis ground stud
5 AC power supply in slot 3 (power supply
zone 1)
— —
9
2 5 6
8 7
431 2
207486
