Cisco ASR 1000 Series Hardware Installation Guide

A-15
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-11
Appendix A Cisco ASR 1000 Series Router Specifications
Cisco ASR 1013 Router Specifications
Cisco ASR 1013 Router Memory and Storage Options
Table A-25 lists the hardware memory and storage options supported on the Cisco ASR 1013 Router.
Cisco ASR 1013 Router Ethernet RJ-45 Port Pinouts
The Cisco ASR 1013 Router has RJ-45 port for the 10/100/1000 Ethernet connections. The RJ-45 port
supports IEEE 802.3ab (Gigabit Ethernet) and IEEE 802.3u (Fast Ethernet) interfaces compliant with
10BASET, 100BASETX, and 1000BASET specifications.
The RJ-45 port supports standard straight-through and crossover Category 5 UTP cables with RJ-45
connectors. Cisco does not supply Category 5 UTP cables; these cables are available commercially.
Cisco ASR 1013 Router MGMT Ethernet Port Signals and Pinouts
Table A-26 lists the RJ-45 port pinout for the front panel Management Ethernet port.
Table A-25 Memory and Storage Options for Cisco ASR 1013 Router
Memory Type Default Maximum System Support
R21– DRAM 8 GB 8 GB
FECP – DRAM 1 GB for ASR1000-ESP-5
2 GB for ASR1000-ESP10
2 GB
eUSB – Internal Flash + NVRAM 8 GB on the integrated RP on
the Cisco ASR 1002 Router
(partitioned: 1 GB for
bootflash; 7 GB for mass
storage)
8 GB – Not Field Upgradeable
Table A-26 Management Ethernet 10/100/1000 RJ-45 Port Pinouts for Cisco ASR 1013 Router
Pin Signal Direction Description
1 TX Data+ Output Transmit Data
2 TX Data– Output Transmit Data
3 RX Data+ Input Receive Data
4, 5 NC — —
6 RX Data– Input Receive Data
7,8 NC — —
