Cisco ASR 1000 Series Hardware Installation Guide

A-16
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-11
Appendix A Cisco ASR 1000 Series Router Specifications
Cisco ASR 1013 Router Specifications
Cisco ASR 1013 Router Console Port Signals and Pinouts
Table A-27 lists the pinouts of the dual RJ-45 ports for the front panel console port.
Cisco ASR 1013 Router Auxiliary Port Signals and Pinouts
Table A-28 lists the pinouts of the dual RJ-45 ports for the auxiliary port signals.
Cisco ASR 1013 Router BITS Port Signals and Pinouts
Table A-29 lists the pinouts of the front panel Building Integrated Timing Supply (BITS) RJ45 port.
Table A-27 Console Port Pinouts for Cisco ASR 1013 Router
Pin Signal Direction Description
1
RTS Output Request to Send (tied to CTS)
2
DTR Output Data Terminal Ready (always On)
3
TXD Output Transmit Data
4
GND — Ring Indicator
5
GND — —
6
RXD Input Receive Data
7
DSR Input unused
8
CTS Input Clear to Send (tied to RTS)
Table A-28 Auxiliary Port Pinouts for Cisco ASR 1013 Router
Pin Signal Direction Description
1
RTS Output Request to Send
2
DTR Output Data Terminal Ready (always On)
3
TXD Output Transmit Data
4
RI — Ring Indicator
5
GND — —
6
RXD Input Receive Data
7
DSR/DCD Input Data Set Ready/Data Carrier Detect
8
CTS Input Clear to Send
Table A-29 BITS RJ-45 Interface Pinouts for Cisco ASR 1013 Router
Pin Signal Direction Description
1 RX Ring Input Receive Ring
2 RX TIP Input Receive TIP (T1/E1)
3, 4 N/C — —
