Appendix B Cisco ASR 1000 Series Router Route Processor and Embedded Services Processor Signals and Pinouts
Cisco ASR1000-RP2 Pinout Specifications
Cisco ASR1000-RP2 Pinout Specifications
The following tables list the pinouts for the ports on the Cisco ASR1000-RP2.
MGMT Ethernet Port Pinouts
Table B-5 lists the RJ-45 port pinouts for the front panel Management Ethernet 10/100/1000 RJ-45 port.
BITS/DTI Interface Port Signals and Pinouts
Table B-6 lists the pinouts of the front panel BITS/DTI RJ45 port.
6
RXD Input Receive Data
7
DSR/DCD Input Data Set Ready/Data Carrier Detect
8
CTS Input Clear to Send
Table B-4 Auxiliary Port Pinouts (continued) for Cisco ASR1000-RP1 (continued)
Pin Signal Direction Description
Table B-5 RJ-45 Management Ethernet Port Pinouts
Pin Signal Direction Description
1 Bi Data A+ Bi Bidirectional Data
2 Bi Data A– Bi Bidirectional Data
3 Bi Data B+ Bi Bidirectional Data
4 Bi Data C+ Bi Bidirectional Data
5 Bi Data C– Bi Bidirectional Data
6 Bi Data B– Bi Bidirectional Data
7 Bi Data D+ Bi Bidirectional Data
8 Bi Data D– Bi Bidirectional Data
Table B-6 BITS/DTI RJ-45 Receptacle Pinouts for Cisco ASR1000-RP2
Pin Signal Direction Description
1 RX Ring Input/Bi (DTI) Receive Ring/Bidirectional (DTI)
2 RX TIP Input/Bi (DTI) Receive TIP (T1/E1)/Bidirectional (DTI)
3, 4 N/C — —
5 TX Ring Output Transmit Ring / unused for DTI
6 TX TIP Output Transmit TIP/ unused for DTI
7,8 N/C — —
