Cisco ASR 1013 Hardware Installation Guide

SPA subslot 13Embedded ASR 1000
Series Route Processor in
the subslot and represents
the built in 4xGE SPA.
1
SPA subslot 34SPA subslot 22
The SPAs in subslots 1-3 are field upgradeable. The SIP that the SPAs reside in is not field-upgradeable
and the Cisco ASR 1000 Series Route Processor is embedded in the chassis and not field upgradeable.
Note
Rear View
Cisco ASR 1002 router AC power supply image shows the Cisco ASR 1002 Router AC power supply.
Figure 80: Cisco ASR 1002 Router AC Power Supply
AC power supply fan5Chassis ESD socket1
AC power supply captive
installation screw
6AC power supply slot
number 0
2
AC power supply slot
number 1
7AC power supply On (|)
/Off (O) switch
3
AC power inlet8AC power supply LEDs4
Cisco ASR 1000 Series Router Hardware Installation Guide
221
Cisco ASR 1002 Router Overview and Installation
Rear View
