If you remove a power supply from a system that has four power supplies that are connected and powered
on, the system can run only for a maximum of five minutes before shutting down. However, because the fans
and power elements are independent within the power supply, the replacement power supply does not have
to be energized within five minutes. The only requirement is that the power supply be installed in the chassis
in order to energize the fans and maintain proper system cooling.
Caution
Step 6
Grasping the power supply handles, pull the power supply from the chassis.
Step 7
Replace the AC power supply within five minutes.
What to Do Next
This completes the procedure for removing the AC power supply from the Cisco ASR 1004 chassis.
Replacing the AC Power Supply in Cisco ASR 1004 Router
This section provides information about installing an AC power supply in the Cisco ASR 1004 Router.
Never install an AC power module and a DC power module in the same chassis. Statement 1050Warning
SUMMARY STEPS
1.
Insert an AC power supply in power supply slot 0 or power supply slot 1 until it is fully seated.
2.
Tighten the captive screws.
3.
Insert the AC power cable.
4.
Plug the power supply cable into the power source.
5.
Turn the power supply Standby switch to On (|) position.
DETAILED STEPS
Step 1
Insert an AC power supply in power supply slot 0 or power supply slot 1 until it is fully seated.
Step 2
Tighten the captive screws.
Step 3
Insert the AC power cable.
Step 4
Plug the power supply cable into the power source.
Step 5
Turn the power supply Standby switch to On (|) position.
What to Do Next
This completes the procedure for installing the AC power supply in the Cisco ASR 1004 Router.
Cisco ASR 1000 Series Router Hardware Installation Guide
558
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing an AC Power Supply in Cisco ASR 1004 Router
