Cisco ASR 1013 Hardware Installation Guide

Table 111: Management Ethernet 10/100/1000 RJ-45 Port Pinouts for Cisco ASR 1002 Router
DescriptionDirectionSignalPin
Transmit DataOutputTX Data+1
Transmit DataOutput
TX Data–
2
Receive DataInputRX Data+3
——
NC4, 5
Receive DataInput
RX Data–
6
——
NC7,8
Cisco ASR 1002 Router Console Port Signals and Pinouts
Unless stated otherwise, the specifications for the Cisco ASR 1002-X Router are the same as the Cisco
ASR 1002 Router specifications listed in this section.
Note
The following table lists the pinout of the dual RJ-45 ports for the front panel console port.
Table 112: Console Port Pinouts for Cisco ASR 1002 Router
DescriptionDirectionSignalPin
Request to Send (tied to
CTS)
OutputRTS1
Data Terminal Ready
(always On)
OutputDTR2
Transmit DataOutputTXD3
Ring Indicator
—
GND4
——
GND5
Receive DataInputRXD6
unusedInputDSR7
Clear to Send (tied to
RTS)
InputCTS8
Cisco ASR 1000 Series Router Hardware Installation Guide
627
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1002 Router Console Port Signals and Pinouts
