Console Port Signals and Pinouts
The following table lists the pinouts of the dual RJ-45 ports for the front panel console port.
Table 133: Console Port Pinouts
DescriptionDirectionSignalPin
Request to Send (tied to
pin 8, CTS)
OutputRTS1
Data Terminal Ready
(always On)
OutputDTR2
Transmit DataOutputTXD3
Ring IndicatorInputRI4
——
GND5
Receive DataInputRXD6
Data Setl Ready/Data
Carrier detect
InputDSR/DCD7
Clear to SendInputCTS8
Auxiliary Port Signals and Pinouts
The following table lists the pinouts of the dual RJ-45 ports for the auxiliary port signals.
Table 134: Auxiliary Port Pinouts
DescriptionDirectionSignalPin
Request to SendOutRTS1
Data Terminal Ready
(Always On)
OutDTR2
Transmit DataOutTXD3
Ring Indicator
—
RI4
——
GND5
Receive DataInRXD6
Cisco ASR 1000 Series Router Hardware Installation Guide
641
Cisco ASR 1000 Series Router Route Processor and Embedded Services Processor Signals and Pinouts
Console Port Signals and Pinouts
