Cisco ASR 1013 Hardware Installation Guide

Table 131: RJ-45 Management Ethernet Port Pinouts
DescriptionDirectionSignalPin
Bidirectional DataBiBi Data A+1
Bidirectional DataBi
Bi Data A–
2
Bidirectional DataBiBi Data B+3
Bidirectional DataBiBi Data C+4
Bidirectional DataBi
Bi Data C–
5
Bidirectional DataBi
Bi Data B–
6
Bidirectional DataBiBi Data D+7
Bidirectional DataBi
Bi Data D–
8
BITS/DTI Interface Port Signals and Pinouts
The following table lists the pinouts of the front panel BITS/DTI RJ45 port.
Table 132: BITS/DTI RJ-45 Receptacle Pinouts for Cisco ASR1000-RP2
DescriptionDirectionSignalPin
Receive
Ring/Bidirectional (DTI)
Input/Bi (DTI)RX Ring1
Receive TIP
(T1/E1)/Bidirectional
(DTI)
Input/Bi (DTI)RX TIP2
——
N/C3, 4
Transmit Ring / unused
for DTI
OutputTX Ring5
Transmit TIP/ unused for
DTI
OutputTX TIP6
——
N/C7,8
Cisco ASR 1000 Series Router Hardware Installation Guide
640
Cisco ASR 1000 Series Router Route Processor and Embedded Services Processor Signals and Pinouts
BITS/DTI Interface Port Signals and Pinouts
