The following image shows the –48 VDC power supply for the Cisco ASR 1002 Router.
Figure 104: – 48 VDC Power Supply for the Cisco ASR 1002 Router
–48 VDC power supply
captive installation screw
6Chassis ESD socket1
–48 VDC power supply
slot 1 label
7
–48 VDC power supply
slot 0 label
2
Ground lead8
–48 VDC power supply
switch Standby/On
3
Positive lead9
–48 VDC power supply
LEDs
4
Negative lead10Fan5
Table 61: Cisco ASR 1002 Router –48 VDC Power Supply LEDs , on page 261 describes the LEDs on the
Cisco ASR 1002 Router –48 VDC power supply.
Cisco ASR 1000 Series Router Hardware Installation Guide
260
Cisco ASR 1002 Router Overview and Installation
Connecting 48 VDC Input Power to Cisco ASR 1002 Router
