The
following
shows
the
Cisco
ASR
1001
Router
AC
power
supply
standby
switch.
Figure 216: Cisco ASR 1001 Router AC Power Supply Standby Switch
Cisco
ASR
1001
Router
Standby
switch,
which
does
not
disconnect
power
from
the
power
source.
1
Cisco ASR 1000 Series Router Hardware Installation Guide
448
Cisco ASR 1001 Router Overview and Installation
Installing AC Input Power to Cisco ASR 1001 Router
481
483
