Table 17: Cisco ASR 1006 Router AC Power Supply LEDs
DescriptionColorLEDLED Label
LED illuminates green to
signal that the AC power
supply input voltage is
greater than 85 V.
GreenPower supply activityINPUT OK
If LED is not illuminated,
then the AC input voltage
is less than 70 V or the
power supply is turned
off. For an AC input
voltage between 70 V and
85V, the INPUT OK LED
can be either on, off, or
flashing
None
LED illuminates green
when all fans are
operational.
GreenBi-color LED indicates
fan status
FAN OK
The LED illuminates red
when a fan failure is
detected.
Red
LED is red and turned off
to signal that the -48 VDC
output voltages are within
the normal operating
range; output voltage
between the minimum
and maximum limits will
not create an output fail
alarm, and output
voltages below the
minimum or above the
maximum will create an
output fail alarm.
When you turn the power
supply on, the red LED is
illuminated for two to
three seconds for testing
LED operation before
going off.
RedPower supply activityOUTPUT FAIL
Cisco ASR 1000 Series Router Hardware Installation Guide
55
Cisco ASR 1000 Series Routers Component Overview
AC Power Supply LEDs and Connector for Cisco ASR 1006
