Cisco Catalyst 3750 - Page 63

2-15
Catalyst 3750 Switch Hardware Installation Guide
78-15136-03
Chapter 2 Product Overview
Front Panel Description
Figure 2-10 Catalyst 3750-24PS and 3750-48PS LEDs
1 Mode button 6 Status LED
2 PoE LED 7 Master LED
3 Stack LED 8 RPS LED
4 Speed LED 9 System LED
5 Duplex LED
RPS
SYST
MASTR
STAT
DUPLX
SPEED
STACK
PoE
MODE
2 3 4 5 7 81
6 9
104062
