Cisco Catalyst 3750 Hardware Installation Guide

Chapter 2 Product Overview
Front Panel Description
2-20
Catalyst 3750 Switch Hardware Installation Guide
78-15136-03
STAT
(port status)
Off No link, or port was administratively shut down.
Green Link present.
Flashing green Activity. Port is transmitting or receiving data.
Alternating
green-amber
Link fault. Error frames can affect connectivity, and errors such as
excessive collisions, CRC errors, and alignment and jabber errors
are monitored for a link-fault indication.
Amber Port is blocked by Spanning Tree Protocol (STP) and is not
forwarding data.
Note After a port is reconfigured, the port LED can remain amber
for up to 30 seconds as STP checks the switch for possible
loops.
Flashing amber Port is blocked by STP and is transmitting or receiving packets.
DUPLX
(duplex)
Off Port is operating in half duplex.
Green Port is operating in full duplex.
SPEED
10/100 and 10/100/1000 ports
Off Port is operating at 10 Mbps.
Green Port is operating at 100 Mbps.
Flashing green Port is operating at 1000 Mbps.
SFP ports
Off Port is operating at 10 Mbps.
Green Port is operating at 100 Mbps.
Flashing green Port is operating at 1000 Mbps.
Note When installed in Catalyst 3750 switches, 1000BASE-T
SFP modules can operate at 10, 100, or 1000 Mbps in
full-duplex mode or in half-duplex mode at 10 or 100 Mbps.
XENPAK port
Off Port is not operating.
Flashing Green Port is operating at up to 10 Gbps.
Table 2-6 Meaning of LED Colors in Different Modes on the Switch (continued)
Port Mode Port LED Color Meaning

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
