Cisco Catalyst 3750 Hardware Installation Guide

Chapter 2 Product Overview
Front Panel Description
2-22
Catalyst 3750 Switch Hardware Installation Guide
78-15136-03
Note If both the port LEDs are green on all the switches in the stack, the stack is
operating at full bandwidth (32 Gbps). If any of the port LEDs are not green, the
stack is not operating at full bandwidth.
Figure 2-11 Stack LED
1 Stack member 8 3 Stack member 4
2 Stack member 3
