1-15
Cisco Nexus 5000 Series Switch CLI Software Configuration Guide
OL-16597-01
Chapter 1 Advanced Fibre Channel Features and Concepts
Default Settings
switch# show fspf internal route vsan 1
FSPF Unicast Routes
---------------------------
VSAN Number Dest Domain Route Cost Next hops
-----------------------------------------------
1 0x61(97) 500 fc2/2
1 0x62(98) 1000 fc2/1
fc2/2
1 0x63(99) 500 fc2/1
1 0x65(101) 1000 fc2/4
Step 8 Verify the name server information.
switch# show fcns data vsan 1
VSAN 1:
------------------------------------------------------------------
FCID TYPE PWWN (VENDOR) FC4-TYPE:FEATURE
------------------------------------------------------------------
0x610400 N 10:00:00:00:c9:24:3d:90 (Emulex) scsi-fcp
0x6105dc NL 21:00:00:20:37:28:31:6d (Seagate) scsi-fcp
0x6105e0 NL 21:00:00:20:37:28:24:7b (Seagate) scsi-fcp
0x6105e1 NL 21:00:00:20:37:28:22:ea (Seagate) scsi-fcp
0x6105e2 NL 21:00:00:20:37:28:2e:65 (Seagate) scsi-fcp
0x6105e4 NL 21:00:00:20:37:28:26:0d (Seagate) scsi-fcp
0x630400 N 10:00:00:00:c9:24:3f:75 (Emulex) scsi-fcp
0x630500 N 50:06:01:60:88:02:90:cb scsi-fcp
0x6514e2 NL 21:00:00:20:37:a7:ca:b7 (Seagate) scsi-fcp
0x6514e4 NL 21:00:00:20:37:a7:c7:e0 (Seagate) scsi-fcp
0x6514e8 NL 21:00:00:20:37:a7:c7:df (Seagate) scsi-fcp
0x651500 N 10:00:00:e0:69:f0:43:9f (JNI)
Total number of entries = 12
Note The Cisco switch name server shows both local and remote entries, and does not time out the entries.
Default Settings
Table 1-3 lists the default settings for the features included in this chapter.
Table 1-3 Default Settings for Advanced Features
Parameters Default
CIM server Disabled
CIM server security protocol HTTP
D_S_TOV 5,000 milliseconds
E_D_TOV 2,000 milliseconds
R_A_TOV 10,000 milliseconds
Timeout period to invoke fctrace 5 seconds
Number of frame sent by the fcping feature 5 frames
Remote capture connection protocol TCP
Remote capture connection mode Passive
