Send document comments to nexus7k-docfeedback@cisco.com.
5-9
Cisco Nexus 7000 Series NX-OS Unicast Routing Configuration Guide, Release 4.x
OL-20002-02
Chapter 5 Configuring WCCPv2
Configuring WCCPv2
DETAILED STEPS
To configure a WCCPv2 service group, use the following command in global configuration mode:
Applying WCCPv2 Redirection to an Interface
To apply WCCPv2 redirection on an interface, use the following commands in interface configuration
mode:
Command Purpose
ip wccp {
service-number
| web-cache}
[mode
{open [redirect-list
acl-name
] | closed
service-list
acl-name
}]] [password [0-7]
pwstring
]
Example:
switch(config)# ip wccp web-cache
Example:
switch(config)# ip wccp 10 password Test1
redirect-list httpTest
Creates an open or closed mode service group.
The service list identifies a named extended IP
access list that defines the packets that will match
the service. This is required only when the service
is defined as closed mode. The service-access-list
can be any case-sensitive alphanumeric string up
to 64 characters.
Optional parameters include:
• mode—Configures the service group in open
or closed mode. The default is open. For
closed mode, configures an IP access list to
define the traffic type that will match this
service.
• password—Configures MD5 authentication
for a service group. Use password 0 pwstring
to store the password in clear text. Use
password 7 pwstring to store the password in
encrypted form. You can use the password 7
keywords for an already encrypted password.
• redirect-list—Configures a global WCCPv2
redirection list for the service group to
control the traffic that is redirected to the
cache engine.
• service-list—Configures an IP access list that
defines the traffic type redirected by the
service group.
The service-number range is from 1 to 255. The
acl-name can be any case-sensitive alphanumeric
string up to 64 characters. The pwstring can be
any case-sensitive alphanumeric string up to eight
characters
