Managing the System
Disk Management
Cisco Small Business NSS300 Series Smart Storage Administration Guide 126
3
Switch the Mapping of a LUN
From the Disk Management > iSCSI > Target Management window, you can
unmap a LUN from the iSCSI target and map it to another target.For the icons
referred to in these steps, refer to Action Icons, page 125.
To switch the mapping of a LUN.
STEP 1 Choose Disk Management > iSCSI > Target Management from the Navigation
menu. The Ta rg et Ma n a g e m e nt window opens.
STEP 2 Select a LUN to unmap from an iSCSI target and click the Disable icon.
STEP 3 Click the Unmap icon to unmap the LUN. The LUN will appear in the Un-Mapped
iSCSI LUN List.
STEP 4 Click the Map icon to map the LUN to another target.
STEP 5 Select the target to map the LUN to and click Apply. The LUN is mapped to the
target.
After creating the iSCSI targets and LUN on the NAS, you can use the iSCSI
initiator installed on your computer (Windows PC, Mac, or Linux) to connect to the
iSCSI targets and LUN and use the disk volumes as the virtual drives on your
computer.
Advanced ACL
From the Disk Management > iSCSI > Advanced ACL window, you can create a
LUN masking policy to configure the permission of the iSCSI initiators that attempt
to access the LUN mapped to the iSCSI targets on the NAS.
View Click this icon to view the connection status of an iSCSI
target.
Action Description
