NSS322 Indicators
Number LED Indicator Description
1HDD1, HDD2 • (Green) Flashes green when the disk drive
data is accessed. Solid green when the disk
drive is accessible.
• (Red) A hard drive read/write error occurs.
LAN (Orange) Flashes when there is network traffic to or
from the NAS. Solid orange when the NAS is
connected to the network.
eSATA (Orange) Flashes orange when an eSATA device is
being accessed.
2Power • (Off) Disk drives are in standby mode or the
device is powered off.
• (Solid Green) The NAS is ready.
• (Flashing Green) One or more of the
following conditions apply:
- The NAS is starting up.
- The NAS is not configured.
- Disk drive is not formatted.
• (Flashing Red) The NAS is in degraded
mode. One of the disk drives failed in RAID 1
configuration.
3 One Touch Copy (Blue) USB device is detected.
NSS322 Front Panel Buttons
Number Item Description
2 Power Button Press Power to power on or shutdown the
NAS.
3 One Touch Copy
Button
Press One Touch Copy to copy files to or from
an external USB drive.
