Cisco WAP321 Administration Guide

Client Quality of Service
Client QoS Association
Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 131
7
To configure client QoS association parameters:
STEP 1 Select Client QoS > Client QoS Association in the navigation pane.
STEP 2 From the VAP list, select the VAP on which you want to configure client QoS
parameters.
STEP 3 Select Enable for the Client QoS Global to enable this feature.
STEP 4 Configure these parameters for the selected VAP:
• Client QoS Mode—Select Enable to enable client QoS functionality on the
selected VAP.
• Bandwidth Limit Down—The maximum allowed transmission rate from the
WAP device to the client in bits per second (bps). The valid range is from 0
to 300 Mbps.
• Bandwidth Limit Up—The maximum allowed transmission rate from the
client to the WAP device in bits per second (bps). The valid range is from 0
to 300 Mbps.
• ACL Type Down—The type of ACL to apply to traffic in the outbound (WAP
device-to-client) direction, which can be one of these options:
- IPv4—The ACL examines IPv4 packets for matches to ACL rules.
- IPv6—The ACL examines IPv6 packets for matches to ACL rules.
- MAC—The ACL examines Layer 2 frames for matches to ACL rules.
• ACL Name Down—The name of the ACL applied to traffic in the outbound
direction.
After switching the packet or frame to the outbound interface, the ACL's
rules are checked for a match. The packet or frame is transmitted if it is
permitted and discarded if it is denied.
• ACL Type Up—The type of ACL that is applied to traffic in the inbound
(client-to-WAP) direction, which can be one of these options:
- IPv4—The ACL examines IPv4 packets for matches to ACL rules.
- IPv6—The ACL examines IPv6 packets for matches to ACL rules.
- MAC—The ACL examines Layer 2 frames for matches to ACL rules.
• ACL Name Up—The name of the ACL applied to traffic entering the WAP
device in the inbound direction.

Cisco WAP321 Specifications

General

Modulation	OFDM
Frequency band	2.4 - 5 GHz
Number of users	32 user(s)
Channels quantity	13 channels
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Certification	FCC class B, CE, IC, Wi-Fi
LED indicators	Power, WAN, WLAN
Supported network protocols	IEEE802.11b/g/n/i/e, 802.3, 802.3u, 802.1X, IPv4, IPv6, HTTP/HTTPS, SNMP
WAN connection	Wi-Fi
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA2, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	275 g
Dimensions (WxDxH)	169.08 x 169.42 x 35 mm
