Captive Portal
Authenticated Clients
Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 154
9
minutes. The default value is 60. The timeout value configured here has
precedence over the value configured for the captive portal instance, unless
the user value is set to 0. When set to 0, the timeout value configured for the
CP instance is used.
Group NameThe assigned user group. Each CP instance is configured to
support a particular group of users.
Maximum Bandwidth UpThe maximum upload speed, in megabits per
second, that a client can transmit traffic when using the captive portal. This
setting limits the bandwidth used to send data into the network. The range
is from 0 to 300 Mbps. The default is 0.
Maximum Bandwidth DownThe maximum download speed, in megabits
per second, that a client can receive traffic when using the captive portal.
This setting limits the bandwidth used to receive data from the network. The
range is from 0 to 300 Mbps. The default is 0.
Delete User—Deletes the current user.
STEP 4 Click Save. The changes are saved to the Startup Configuration.
Authenticated Clients
The Authenticated Clients page provides information about clients that have
authenticated on any Captive Portal instance.
To view the list of authenticated clients, select Captive Portal > Authenticated
Clients in the navigation pane.
MAC AddressThe MAC address of the client.
IP AddressThe IP address of the client.
User NameThe Captive Portal user name of the client.
ProtocolThe protocol the user used to establish the connection (HTTP or
HTTPS).
VerificationThe method used to authenticate the user on the Captive
Portal, which can be one of these values:
- GuestThe user does not need to be authenticated by a database.
