Client Quality of Service
Client QoS Status
Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 132
7
When a packet or frame is received by the WAP device, the ACL's rules are
checked for a match. The packet or frame is processed if it is permitted and
discarded if it is denied.
• DiffServ Policy Down—The name of the DiffServ policy applied to traffic
from the WAP device in the outbound (WAP-to-client) direction.
• DiffServ Policy Up—The name of the DiffServ policy applied to traffic sent
to the WAP device in the inbound (client-to-WAP) direction.
STEP 5 Click Save. The changes are saved to the Startup Configuration.
Client QoS Status
The Client QoS Status page shows the client QoS settings that are applied to each
client currently associated with the WAP device.
To show the Client QoS Status page, select Client QoS > Client QoS Status in the
navigation pane.
Use these fields to configure Client QoS Status:
• Station—The Station menu contains the MAC address of each client
currently associated with the WAP device. To view the QoS settings
applied to a client, select its MAC address from the list.
• Global QoS Mode—Whether QoS is enabled globally on the WAP device.
This status is configured on the Client QoS Association page.
• Client QoS Mode—Whether QoS is enabled on the associated VAP. This
status is configured on the Client QoS Association page.
• Bandwidth Limit Down—The maximum allowed transmission rate from the
WAP device to the client in bits per second (bps). The valid range is from 0
to 4294967295 bps.
• Bandwidth Limit Up—The maximum allowed transmission rate from the
client to the WAP device in bits per second (bps). The valid range is from 0
to 4294967295 bps.
• ACL Type Up—The type of ACL that is applied to traffic in the inbound
(client-to-WAP) direction, which can be one of these options:
- IPv4: The ACL examines IPv4 packets for matches to ACL rules.
